Balboa Topside Controllers & Overlays
from $13.31
22074102, VL260 Large Balboa TopSide Controller (For One Pump Systems)  (Measures roughly 7" wide) 4 Button22074112, Overlay for 22074102 (no longer available)
22074122, VL260 Generic Large Balboa Overlay for 22074102
22074101, VL200 Small Balboa Topside Controller (For One Pump Systems)  (Measures roughly 4 3/8" x 1 5/8")22074111, VL200 Small Balboa Overlay for 22074101
22074114, VL401 Large Balboa Overlay (For One Pump System) - Rectangular
Compatible with Nordic Hot Tubs
Balboa TP600 Topside Overlay
$30.95
Topside Overlay (Jets 1, Aux, Flip) for Balboa TP600
Details
Product Code: R6021707
Bracketless Emerson 56 Frame Pump Parts (5/2009+)
from $3.21
Please note: These are the Emerson-made version of these pumps. The LX-made pumps are more common (click here for the LX-made versions). You can replace the LX-made pump with an Emerson pump. However, pump parts are not interchangeable. The label will indicate if it is LX or Emerson.
Â
Â
Universal Mounts are available for the J-LX, J-500, J-400, J-300, and J-100 Series hot tubs. Find the specifical hot tub parts and their specifications below:Â
Â
J-LX/J-LXL/J-500/J-400/J-300/J-100 North America 60HzÂ
6500-352S Universal Bracket Mount, 1-Speed
6500-365 Universal Bracket Mount, 1-Speed
6500-367Â Universal Bracket Mount, 2-Speed
6500-363 Universal Bracket Mount, 1-Speed
Â
Pump Parts
Union Assembly, Straight (O- 6500-232 Ring Included)
Union Assembly, 45° 6500-037 (O-Ring Included)
Union O-Ring (1 ea.) 6000-645
Drain Plug with O-Ring (1 ea.) 6500-547
Screw, Self-Tapping (1 ea.) 6500-548
Housing, Front (Volute) 6500-546
Housing O-Ring 6500-545
Impeller, 2.5hp 6500-549
Seal-Plate, rotation 6500-544
Seal, ceramic, Stationary for North American 60Hz Pumps 6500-543
Rear housing 6500-541
Adapter, 1/4-18 NSPM thread x 3/8" Barb, Stainless Steel 6540-171 **Requires new o-ring 6540-263
O-Ring, 0.434" ID x 0.682" OD x 0.125" 6540-263
Run Capacitor 2.5hp (1&2 Speed Emerson Motors Only) 6000-163
Bracketless LX 56 Frame Pump Parts (5/2009+)
from $0.29
J-LX/J-LXL/J-500/J-400/J-300/J-200/J-100 North America 60Hz Bracketless LX 56 & 48 Frame Pump Parts (5/2009+)
Â
Compatible Pumps (LX Version; Not Emerson)
6500-352S
6500-365S
6500-367S
6500-363S
6500-845S
6500-090S
6500-357S
Â
6500-232 Union Assembly, straight (o-ring included)
6500-037 Union Assembly, 45 degree (o-ring included)
6000-645 Union o-ring
6500-601 Screw, Self-Tapping (1 ea)
6500-602 Drain Plug
6500-603 Drain Plug O-Ring
6540-171 Adapter, 1/4-18 NSPM thread x 3/8" Barb, Stainless Steel (replaced 6540-030)
6540-263 O-Ring, 0.434"ID x 0.682" OD x 0.125"Â
6500-604 Housing, Front (Volute) 56FR
6500-605Â Housing O-Ring
6500-612Â Impeller, 2.5hp (Used on 1 & 2 Speed Motors)
6500-281Â Seal-Stationary ASM (PS200)
6500-606 Housing Rear 56FR
6500-613 Run Capacitor 2.5HP (for 1 & 2 speed LX motors ONLY)
Button / Light For Clearblue Ionizer
$64.95
Button / Light for Clearblue Ionizer included with most Swimlife Swim Spas.This Product is a Special Order and is not in stock. Unfortunately, we cannot provide an ETA for special order items. Items placed as Special order are non-refundable, and orders for special ordered items cannot be cancelled.Please see our refund policy at https://www.hottubstore.ca/pages/refund-policy for more information.If a special order item is ordered with other non-special order items, it will delay the entire order.
Cal Spas Recessed Pillow (2020)
$82.95
*This product is special order - please expect an additional delay receiving this part.
Cal Spas Pillow with F-O-Y Recess (black) for 2019+ hot tubs.
Details
Cal Spas F-O-Y Recessed Pillow - Black (2020)
Pillow Model #S-01-4285
Part #ACC01401101-1
For select 2019+ models only
Compatible with
Wellness Shop Spas
Rejuvenation Spas
OC Spas
Capri™, Dover™ SunStrong® Extreme Cover
$995.00
Need a Hot Tub Cover now? Check out our list of In-Stock Covers
*Fits Sundance 880 Capri (2006+) and Sundance 780 Dover (2008+) Models.
Celebrity & Sunrise Pillows
$36.95
Please note:Â These products may not be stocked and as a result delivery may be delayed.
Â
R9015900 8515080 8515093:Â 2-pin, graphite colour, tri-curved pillow
Celebrity Air Valve and Knob
from $5.95
Air valve and knob for the Celebrity C-78 and C-84 hot tub. Also used in Sunrise (and other) hot tubs.
R3035164, Handle (knob), S-Style, DSG, fits Sure Grip Mounting system (alternative part number #662-2169-DSG)
R3035160, Air Control, Sure Grip Mounting System (SGMS) and TT Cap (alternative part number #668-0009LH-TT)
Â
Â
Celebrity Valve
$22.95
Please note: There are other part selections. Please do not purchase this part unless you know it is required. You may speak with our team to identify the part that you need.
R3035150, Diverter cap and stem
Circuit Board: J-200 & J-100 LCD Series
from $870.95
Circuit boards are available for sale for the J-200 and J-100 LCD Series Hot Tubs. Part numbers will vary depending on the hot tub model. Refer to the list below for the correct part number.Â
J-200 North American 60Hz Models (2018+)
6600-268, All 2018+ 1 & 2-Pump J-200 & J-100 Models (Microprocessor Based)
J-200 LED Series (2014-2017) & J-100 LED Series (2016-2017)
6600-720, All 2014-2017 J-280, J-275, J-245, J-235 2-Pump Models, Micro Chip 5.60A Included
6600-722, All 2014-2017 J-210 and 2016-2017 J-225, J-215 1-Pump Models, Micro Chip 5.60A Included
Circuit Board: J-300 LCD Series
from $844.95
J-300 North American 60Hz Models (2020+)
6600-505Â All 2 pump J-300 models 2020+. Encrypted board.
6600-499, All 1 pump J-300 models 2020+. Encrypted board.
J-300 North American 60Hz Models (06/2018-2019)
6600-412, All 1 Pump J-300 models 06/2018-2019. Encrypted board. Will not work with older control panels. When used in pre- 06/2018 spas needs to be reprogrammed with a Pick-iT kit.
6600-420, Replaced by 6600-505 All 2 Pump J-300 models 06/2018- 2019. Encrypted board. It will not work with older control panels. When used in pre-06/2018 spas needs to be reprogrammed with a Pick-iT kit.Replaced by 6600-505
J-300 North American 60Hz Models (2016-05/2018)
6600-784, All 2016-05/2018 2-Pump Domestic 60Hz J-385, J-375, J-365, J-355, J-345, J-335 Models. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
6600-786, All 2016-05/2018 1-Pump Domestic 60Hz J-325, J-315 Models.Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
J-300 Export 50Hz Models
6600-785, All 2016-05/2108 2-Pump Export 50Hz J-385, J-375, J-365, J-355, J-345, J-335 Models. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
6600-783, All 2016-05/2018 1-Pump Export 50Hz J-325, J-315 Models. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
Circuit Board: J-300 LED Series (2002-2015)
from $43.95
J-300 North American 60Hz And Export 50Hz Models
Note: Product may not be in stock at time of order and order may be delayed. Â Please contact us for stock inquiry.
6600-296, All 2014-2015 1-Pump J-325, J-315 Models, Micro Chip 3.83 Included. Â Note: Replaces 6000-296
6600-297, All 2014-2015 2-Pump J-385, J-375, J-365, J-355, J-345, J-335 Models. Replaces 6000-293
6600-724, 2002-2013 1-Pump J-300 models (except 2002-2003 J320 & 2005-2007 J325)
*Please message us before ordering to ensure you are receiving the correct product needed.Â
Â
6660-289, Micro Chip Rev 3.82 (used with all 2014-2015 J-300 LED 1-Pump & 2-Pump spas with circulation pumps)
Circuit Board: J-400 LCD Series
from $998.95
Please note: circuit boards may not be in stock at the time of order and delivery may be delayed. Please contact our team to confirm current stock.
J-400 North American 60Hz Models (04/2018+)
6600-478Â All 2019+ J485, J475, J445, J435, and 2020+ J425 models. Encrypted board. It will not work with older control panels.
6600-422Â All 1 or 2-Pump J-400 models 04/2018 - 2019, EXCEPT J-435/J-445/J-475/J-485. Encrypted board. It will not work with older control panels. When used in pre 04/2018 spas need to be reprogrammed with the Pick-iT kit.
6600-430Â J-435/J-445 models 04/2018-2018. Encrypted board. Will not work with older control panels. When used in pre-04/2018 spas needs to be reprogrammed with Pick-iT kit.
6600-476, All 3 Pump J-400 models 04/2018+. Encrypted board. Will not work with older control panels. When used in pre-04/2018 spas needs reprogrammed with Pick-iT kit.
J-400 LCD Series (09/2015-03/2018)
6600-766Â All 09/2015-03/2018 1&2 Pump J-400 models (Not Compatible with 10/2017+ J-445 & J-435 models). Board is microprocessor controlled, includes factory-installed jumper wires and does not require an Eprom.
6600-266Â For 2-Pump Domestic 60Hz J-445 & J-435 10/2017-3/2018 models only. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
6600-768Â All 09/2015-03/2018 3-Pump J-495 models. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
J-400 Export 50Hz Models
6600-765Â All 09/2015-03/2018 1&2 Pump J-400 models (Not Compatible with 10/2017+ J-445 & J-435 models). Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
6600-767, All 09/2015-03/2018 3-Pump J-495 models. Board is microprocessor controlled, includes factory installed jumper wires and does not require an Eprom.
J-400 LCD Series (2006-08/2015)
6600-728, All 2008-Mid 12/2009Â Â 1&2 Pump J-400 models with 1-speed Jet Pump Board is microprocessor controlled and does not require an Eprom.
